Double shafts design.
Reasonable load and run stably.
Suitable for various profiles, both for flat and bevel flanges.
|
WLL (T) |
TEST LOAD(kN) |
I-BEAM(MM) |
A |
B |
C |
D |
E |
F |
G |
H |
J |
K |
L |
M |
N.W(KG) |
|||
|
a |
b |
a |
b |
a |
b |
|||||||||||||
|
0.5 |
7.5 |
50~152 |
50~203 |
108 |
286 |
200 |
190 |
108 |
53 |
94 |
18.5 |
78 |
57 |
37 |
14 |
24 |
6 |
6.5 |
|
1 |
15.0 |
64~203 |
64~305 |
115 |
405 |
238 |
211 |
115 |
59 |
120 |
24 |
90 |
66 |
40 |
16 |
28 |
11.5 |
13 |
|
2 |
30.0 |
88~203 |
88~305 |
130 |
419 |
274 |
236 |
130 |
69 |
136 |
26 |
105 |
75 |
44 |
17 |
34 |
18 |
20 |
|
3 |
45.0 |
100~203 |
100~305 |
164 |
435 |
314 |
295 |
164 |
82 |
150 |
33 |
130 |
96 |
60 |
17 |
34 |
30 |
34 |
|
5 |
75.0 |
114~203 |
114~305 |
177 |
457 |
364 |
334 |
177 |
97 |
169 |
38 |
150 |
112 |
65 |
22 |
40 |
44 |
46 |
|
10 |
150 |
124~203 |
124~305 |
378 |
480 |
480 |
460 |
237 |
130 |
198 |
55 |
189 |
150 |
90 |
27 |
57 |
82 |
89 |
